Specifications
|
|
Part number
|
300/242AW600
|
300/242AW601
|
300/242AW602
|
|
Frequency range
|
2400 ~ 2480MHz
|
5150 ~ 5350MHz
|
5725 ~ 5825MHz
|
|
VSWR
|
2.0 max
|
|
Gain
|
3.0 dB max
|
5.0 dB max
|
4.0 dB max
|
|
Impedance
|
50 Ohm nom
|
|
Polarization
|
Vertical
|
|
Radiation
|
Omni
|
|
Electrical wave
|
1/4λ Dipole
|
|
Connector
|
I-PEX standard, others available (please, specify)
|
|
Connector base
|
Brass, gold plated
|
|
Antenna swivel cover
|
PC/ABS, black
|
|
Connector shell
|
Brass
|
|
Cable
|
Coax, 1.13mm O.D. standard, other available (please, specify)
|
|
Operating temperature
|
-20°C to +65°C
|
|
Storage temperature
|
-30°C to +75°C
|
|
