Specifications
|
|
Frequency range
|
2400 ~ 2483.5MHz
|
|
Impedance
|
50 Ohm nom
|
|
VSWR
|
2.0 max
|
|
Gain
|
10.0 dB max
|
|
Polarization
|
Liner
|
|
Radiation
|
Direction
|
|
Electrical wave
|
1/4λ Dipole
|
|
Connector
|
SMA jack, straight standard, others available (please, specify)
|
|
Connector base
|
Brass, gold plated
|
|
Antenna cover
|
PC/ABS, black
|
|
Antenna post
|
SPCC
|
|
Operating temperature
|
-20°C to +65°C
|
|
Storage temperature
|
-30°C to +75°C
|
|
